АКБ VISION HP&HF Series
Добавить в избранное
The new VISION HP&HF series batteries are specially designed for applications that require high power output. By optimum design of battery grids and plate paste formula, the HP&HF series can deliver up to 40% more power than VISION standard CP&FM series.
Features and Benefits
• Environmentally friendly
• Lower internal Resistance
• Positive and negative plates in lead-calcium tin alloy
• Superior energy density and very high power output
• Operates at a low internal pressure
• Gas Recombination
• A recognized component of UL
• Lead calcium grids for extended life Six months shelf life at 20℃
• Power range from 13W to 890W per cell for 10min@1.60V/cell
• Design life: HP-5 years, HF-10 years
General Features
• Environmentally friendly
• High Reliability and Good Quality
• Lower internal Resistance
• High Power Density
• Long Service Life, in Float and Cyclic
• International Standard, JIS and DIN
• Thick pasted plates with high quality
• lead-tin-calcium alloy grids for long service life
Applications
• Office machines and Computers
• Telecommunications
• UPS Equipment
• Electrical facilities
• Vending machine
.jpg)
| Type | Nominal Voltage(V) | Nominal Capacity /WPC (10min 1.60V) | Nominal Capacity /AH | Length | Width | Height | Total Height | Terminal | Weight(Approx) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | mm | in | Kg | Pound | |||||
| HP12-30W | 12 | 30 | 5 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 107 | 4.21 | F1 | 1.80 | 3.97 |
| HP12-50W | 12 | 50 | 9 | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.94 | F2 | 2.80 | 6.17 |
| HP12-105W-X | 12 | 105 | 17 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.57 | F13 | 5.90 | 13.01 |
| HP12-116W-X | 12 | 116 | 20 | 181 | 7.13 | 77 | 3.03 | 167 | 6.57 | 167 | 6.57 | F13 | 6.20 | 13.70 |
| HF12-155W-X | 12 | 155 | 28 | 165 | 6.50 | 125 | 4.92 | 175 | 6.89 | 175 | 6.89 | F13 | 9.60 | 21.20 |
| HF12-165W-X | 12 | 165 | 33 | 195 | 7.68 | 130 | 5.12 | 155 | 6.10 | 168 | 6.61 | F11 | 11.1 | 24.50 |
| HF12-211W-X | 12 | 211 | 45 | 197.5 | 7.78 | 165.5 | 6.52 | 170 | 6.69 | 170 | 6.69 | F11 | 14.8 | 32.60 |
| HF12-260W-X | 12 | 260 | 55 | 229 | 9.02 | 138 | 5.43 | 208 | 8.19 | 213 | 8.39 | F11 | 17.2 | 37.90 |
| HF12-320W-X | 12 | 320 | 75 | 258 | 10.20 | 166 | 6.54 | 206 | 8.11 | 215 | 8.46 | F11 | 23.0 | 52.70 |
| HF12-370W-X | 12 | 370 | 80 | 350 | 13.80 | 167 | 6.57 | 179 | 7.05 | 179 | 7.05 | F11 | 26.2 | 57.80 |
| HF12-420W-X | 12 | 420 | 90 | 306 | 12.00 | 169 | 6.65 | 210 | 8.27 | 215 | 8.46 | F12/F21 | 28.0 | 61.70 |
| HF12-470W-X | 12 | 470 | 100 | 330 | 13.00 | 171 | 6.73 | 215 | 8.46 | 220 | 8.66 | F12 | 33.0 | 72.80 |
| HF12-560W-X | 12 | 560 | 120 | 410 | 16.10 | 176 | 6.93 | 224 | 8.82 | 224 | 8.82 | F12 | 37.7 | 83.10 |
| HF12-600W-X | 12 | 600 | 134 | 341 | 13.40 | 173 | 6.81 | 283 | 11.10 | 287 | 11.30 | F15 | 41.5 | 91.50 |
| HF12-650W-X | 12 | 650 | 150 | 482 | 19.00 | 170 | 6.69 | 240 | 9.45 | 240 | 9.45 | F12 | 46.4 | 102.00 |
| HF12-890WS-X | 12 | 890 | 200 | 522 | 20.60 | 238 | 9.37 | 218 | 8.58 | 223 | 8.78 | F10 | 67.5 | 149.00 |
| HF12-1010W-X | 12 | 1010 | 210 | 522 | 20.60 | 238 | 9.37 | 218 | 8.58 | 223 | 8.78 | F10/F38 | 67.0 | 148.00 |
| HFS12-400W-X | 12 | 400(15min/1.67V) | 306 | 13.00 | 169 | 6.73 | 210 | 8.46 | 215 | 8.66 | F12 | 32.5 | 71.60 | |
| HFS12-450W-X | 12 | 450(15min/1.67V) | 339 | 16.10 | 173 | 6.93 | 215 | 8.82 | 220 | 8.82 | F12 | 36.5 | 80.50 | |
| HFS12-550W-X | 12 | 550(15min/1.67V) | 482 | 19.00 | 170 | 6.69 | 240 | 9.45 | 240 | 9.45 | F10 | 45.0 | 98.00 | |
| HFS12-800WS-X | 12 | 800(15min/1.67V) | 522 | 20.55 | 238 | 9.37 | 218 | 8.58 | 223 | 8.78 | F38 | 67.5 | 134.48 | |
